Brand Name : ZD
Model Number : ZD-SLA-825-6/13NF
Certification : RoHS
Place of Origin : China
MOQ : Negotiable
Price : Negotiable
Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram, L/C
Supply Ability : 10000pcs one month
Delivery Time : 3-15 days
Packaging Details : Standard exporting cartons or as customer required
Frequency range(MHz) : 800-2500
Gain(dBi) : 6-8/13
Connector : N-F
Input Impedance(Ω) : 50
Lighting Protection : DC Ground
Operating Temperature(°) : -40~+60
Popular style 800-2500MHz Street Light Antenna outdoor
Application
1) Long distance Signal Transmission
2) Wireless Bridge
3) Widely used for residential area and square
Good Performance and Running characteristic
Electrical parameters | |||
Frequency range(MHz) | 824-960/1710-2500 | 824-960/1710-2500 | |
Gain(dBi) | 6-8 | 13 | |
VSWR | ≤1.5 | ≤1.5 | |
Polarization | V | ||
Electrical Head Angle(°) | 9~15 | 9~15 | |
Input Impedance(Ω) | 50 | ||
Horizontal Beamwidth (°) | 360 | 360 | |
Vertical Beamwidth (°) | 36-22/23-16 | 36-22/23-16 | |
Input Power per Port(W) | 50 | ||
Connector | N-Female | ||
Lighting Protection | DC Ground | ||
Mechanical parameter | |||
Antenna Dimensions(mm) | 76*1900 | 76*1850 | |
All Dimention(mm) | 3080-3100 | 3050-3080 | |
Cover Material | Fiberglass | ||
Weight(kg) | 5.2 | 5.2 | |
Installation | Embed to cage installation | ||
Rated Wind Velocity(m/s) | 60 | ||
Operating Temperature(°) | -40~+60 |
![]() |
Embellished Antenna outdoor for Road lamp street lighting 800-2500MHz Images |
