RF DCS/UMTS Poi Point Of Interface8 IN 2 OUT POI Combiner 3x1800MHz & 3x2100MHz

Product Categories
SHENZHEN ZD TECH CO., LTD
Contact Now

RF DCS/UMTS Poi Point Of Interface8 IN 2 OUT POI Combiner 3x1800MHz & 3x2100MHz

  • 1
  • 2

Brand Name : ZD

Model Number : ZD-POI-1821-8DF2NF

Certification : RoHS

Place of Origin : CHINA

MOQ : negotiable

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 3-4 weeks

Packaging Details : wooden box

product : 8 in 2 out POI

Frequency : 1800/2100MHz

Application : indoor

Insertion Loss (dB) : ≤8.5

Isolation Between Bands (dB) : ≥22

Impedance(Ω) : 50

Contact Now

RF DCS/UMTS 6 IN 2 OUT POI Combiner 3x1800MHz &3x2100MHz point of interface



RF DCS/UMTS Poi Point Of Interface8 IN 2 OUT POI Combiner 3x1800MHz & 3x2100MHzRF DCS/UMTS Poi Point Of Interface8 IN 2 OUT POI Combiner 3x1800MHz & 3x2100MHz

Electrical Specifications



Input Port information (MHz)







DCS1 1800



 RX/TX (A): 1710-1770/1805-1865
RX/TX (B): 1710-1770/1805-1865
RX/TX (C): 1710-1770/1805-1865

UMTS 2100



 RX/TX (A): 1920-1980/2110-2170
RX/TX (B): 1920-1980/2110-2170
RX/TX (C): 1920-1980/2110-2170
Insertion Loss (dB) ≤8.5
Isolation Between Bands (dB) ≥22
Isolation Cross Bands (dB) ≥50
Iput port Return Loss (dB) ≥18
Power Handling(W) 100
Intermodulation Products (dBc) ≤-150@2*43dBm
Impedance(Ω) 50
Number of Monitors Ports (-30dB± 2)


































Mechanical Specifications



Dimensions,LxWxH(mm)/(in)

(excluding connectors&mounting bracket)

 TBD
Weight(kg)/(lb) TBD
Shipping Dimensions,LxWxH(mm)/(in) TBD
Shipping Weight (kg)/(lb) TBD



RF Connectors

 Input & Output Ports 8 x DIN - Female
Monitors Ports 2x N-Female
Mounting 19＂ Rack
Operating Temperature Range (℃) -10 to+60
Operational Humidity (%) ＜95
Environmental Class Indoor



Block Diagram:



RF DCS/UMTS Poi Point Of Interface8 IN 2 OUT POI Combiner 3x1800MHz & 3x2100MHz
